Description
Technical Highlights (6.5kW Model)
- Rated Output Power: 6.5kW
- PV Input Power: Increased solar input for larger arrays
- MPPT Efficiency: Up to 99%
- Battery Support: 48V systems with high-charge capability
- Surge Capacity: Handles demanding appliances effortlessly
- Transfer Time: Fast switching for uninterrupted backup
- Output Waveform: Pure sine wave suitable for all electronics
Full Technical Specifications (Rewritten for U.S. Installers)
PV (Solar Input)
- Max PV Input Power: ~8500W
- Max PV Voltage (Voc): 500V
- MPPT Voltage Range: 150V–450V
- Number of MPPT Trackers: 1
- Max PV Input Current: 18A
AC Output
- Rated Output Power: 6500W
- Output Voltage: 120/240V split-phase compatible (via configuration)
- Output Frequency: 50/60Hz
- Surge Power: Up to 13,000W (few seconds)
- Power Factor: 1.0
Battery Specifications
- Battery Voltage: 48V nominal
- Compatible Battery Types:
- Lithium (LFP ideal)
- AGM
- GEL
- Max Charging Current: 120A
- Max Discharging Current: 120A
Charging & Efficiency
- Max Solar Charging Efficiency: 99%
- AC Charging Efficiency: 95%
- Supports Solar + Grid + Generator charging
Protection Features
- PV Overvoltage Protection
- Battery Overcurrent Protection
- Overload Protection
- Short-Circuit Protection
- Over-temperature Shutdown
- Anti-Islanding Protection
- Reverse Polarity Protection
Smart Features
- Remote monitoring (app + web dashboard)
- Adjustable battery charging profiles
- System event logging and diagnostics
- Programmable time-of-use (TOU) modes
- Intelligent load management
Certifications
- UL 1741 (Equivalent compliance—pending client confirmation)
- FCC Approved
- IEC 62109 Safety Compliance
Physical Data
- Mounting: Wall-mounted compact design
- Weight: Medium-weight for ta wo-person lift
- Cooling Method: Intelligent fan cooling
- Enclosure: Indoor/outdoor rated (IP level TBD)
Ideal Applications
- Mid-sized homes
- Solar-plus-storage systems
- Farms and workshops
- Hybrid energy systems needing stable output
- Light commercial installations
- Multi-room residential loads
Why Installers Choose the LDS Energy 6.5kW Model
- Ideal balance of size, output, and reliability
- Supports larger household loads with ease
- Strong MPPT and surge performance for demanding systems
- Fast distributor availability and reliable customer support
- Tough enough for U.S. climates and diverse installation needs
- A trusted mid-range option for contractors who need consistent results
